Crisp 128x64 Pixel FSTN+ Gray Graphic LCD with White Backlight
The NHD-C12864DA-FSW-FBW-3V3 is the perfect solution for presenting information and clean monochrome visuals in your next build. With a 128x64 pixel FSTN+ Gray LCD display, White backlight, and a transflective screen, it ensures easy readability across various lighting conditions. Its 6:00 viewing angle can be viewed clearly from multiple positions. The integrated ST7565R controller communicates via a Serial/Parallel interface, making it easy to integrate into Arduino and similar development board projects.
This display is a chip-on-glass design, which allows you more flexibility in incorporating it into your design because it is not bonded to a PCB. It runs on low 3.0V power for more efficient applications. It operates between -20° and 70° C, making it dependable in extreme conditions, and it is RoHS compliant for environmental safety.
NHD-C12864DA-FSW-FBW-3V3: Technical Specifications
| Display Format | 128x64 Pixels |
|---|---|
| Display Type | FSTN (+) Gray |
| Display Mode | Transflective |
| Optimal View | 06:00 |
| Outline L x W x H | 58.2mm x 14.7mm x 5.7mm |
| Viewing Area L x W | 50mm x 25mm |
| Active Area L x W | 46.05mm x 23.01mm |
| Supply Voltage | 3V |
| Backlight | White |
| Interface | Serial / Parallel |
| Compatibility | Arduino and Similar Development Boards |
| Controller Type | ST7565R |
| Connection Type | 1x28 Pins with 1.27mm Pitch |
| Operating Temperature | -20° ~ 70° C |
| Storage Temperature | -30° ~ 80° C |
