Adaptable 16x2 Blue Modular Character OLED
This 16x2 character OLED screen is an excellent solution for projects that require clean, crisp text or numeric output. Its vivid blue text stands out clearly against a black background, ensuring great visibility from any direction. It also has double-height characters, giving you greater customization to make sure that your message comes across loud and clear. Built for Arduino or similar development boards, it uses a reliable US2066 controller and supports an I2C interface for quick and easy integration.
The NHD-0216AW-IB3 is designed to withstand extremes, operating in a temperature range from -40° to 85° C, so you can push your product to its limits without compromise or need for additional heating elements. It runs on 3.3V or 5.0V power, making it adaptable to the needs of your design, and all components are RoHS compliant for environmental safety.
NHD-0216AW-IB3: Technical Specifications
| Size | 2 Row | 16 Characters |
|---|---|
| Display Format | 16x2 |
| Total Characters | 32 |
| Display Type | Modular Character OLED |
| Display Color | Blue |
| Outline L x W x H | 49.2mm x 25.7mm x 4.5mm |
| Viewing Area L x W | 36.22mm x 11.4mm |
| Active Area L x W | 34.22mm x 9.4mm |
| Character Height | 4.45mm |
| Supply Voltage | 3.3V or 5.0V |
| Interface | I2C |
| Compatibility | Arduino or Similar Development Boards |
| Controller Type | US2066 |
| Connection Type | 1x7 Thru Hole with 2.54mm Pitch |
| Operating Temperature | -40° ~ 85° C |
| Storage Temperature | -40° ~ 90° C |
| Additions | 1x7 Thru Hole Connector, Double Height Characters |
