7-tums IPS TFT-skärm med hög ljusstyrka och RGB-gränssnitt för tydlig och energieffektiv bildåtergivning vid beröringsfria tillämpningar
This 7.0" IPS TFT LCD delivers 800x480 resolution with vivid colors, wide viewing angles, and sharp contrast for consistent, high-quality visuals. Its 1,000-nit LED backlight ensures excellent readability in indoor, outdoor, and direct sunlight conditions.
Designed without touch functionality, this display is ideal for projects that require premium graphics with simplified implementation and lower power consumption.
Featuring a 24-bit parallel RGB interface and a Flexible Flat Cable (FFC) connection with EMI shielding, integration with Arduino boards and other compatible systems is fast and reliable. Powered by a built-in ST7277 driver, this module provides smooth graphics rendering, dependable performance, and optimized display functionality. Like all Newhaven Display products, it is RoHS compliant and built to meet strict environmental and safety standards.
NHD-7.0-800480AF-ASXP: Tekniska specifikationer
| Size | 7" Diagonal |
|---|---|
| Resolution | 800x480 Pixels |
| Colors | 16.7M |
| Display Type | IPS |
| Display Mode | Transmissive |
| Optimal View | Full View |
| Touchscreen | None |
| Outline L x W x H | 165mm x 104mm x 3.5mm |
| Viewing Area L x W | 156.7mm x 88.1mm |
| Supply Voltage | 3.3V |
| Luminance | 1,000 Nits |
| Interface | 24-Bit Parallel RGB |
| Compatibility | Arduino and similar development boards |
| Controller/Driver | ST7277 |
| Connection Type | 40-Pin 0.5mm Pitch FFC |
| Operating Temperature | -20° C ~ 70° C |
| Storage Temperature | -30° C ~ 80° C |
| Built-In Mounting | No |
| EMI Shielding | Yes |
