Sharp 40x4 FSTN (+) Gray Character LCD with No Backlight
The NHD-0440AZ-RN-FBW is the perfect fit for your next project. It has a FSTN (+) Gray display with no backlight and a reflective screen that enhances visibility in well-lit spaces. With a wide 6:00 viewing angle, it's easy to read from different directions. The high-performance ST7066U controller and easy-to-use Parallel interface make Arduino and similar development board integrations simple-so you can spend more time building and less time troubleshooting.
This display runs on a standard 5.0V supply, operates between -20° and 70° Celsius, and is RoHS compliant, making it environmentally friendly, even if the environment might not be friendly to it.
NHD-0440AZ-RN-FBW: Technical Specifications
| Size | 4 Row | 40 Characters |
|---|---|
| Display Format | 40x4 |
| Total Characters | 160 |
| Display Type | FSTN (+) Gray |
| Display Mode | Reflective |
| Optimal View | 06:00 |
| Outline L x W x H | 79mm x 36mm x 13mm |
| Viewing Area L x W | 60mm x 28mm |
| Active Area L x W | 56.5mm x 23.6mm |
| Supply Voltage | 5V |
| Backlight | None |
| Interface | Parallel |
| Compatibility | Arduino and Similar Development Boards |
| Controller Type | ST7066U |
| Connection Type | Two 1x8 Pins with 2.54mm Pitch |
| Operating Temperature | -20° ~ 70° C |
| Storage Temperature | -30° ~ 80° C |
