Versatile IPS TFT display for vibrant, touch-free applications.
This 2.4" IPS TFT LCD offers 240x320 resolution, full viewing angles, and a 450-nit LED backlight for clear, vivid visuals in compact designs. With IPS technology and a low 3.0V power requirement, it delivers sharp color and consistent image quality while keeping power usage low.
Optimized for projects that don't require touch input, this display is powered by the ILI9341V controller and supports a wide range of interface options-8/9/16/18-bit Parallel, 6/16/18-bit RGB, and 3/4-wire SPI-for seamless integration into diverse embedded systems and Arduino-compatible platforms.
It features a 45-pin FFC with 0.5mm pitch and built-in EMI shielding for signal protection and noise reduction in electrically sensitive environments. RoHS compliant and affordably built for both performance and efficiency, this module is ideal for control panels, display readouts, instrumentation, and compact embedded systems.
NHD-2.4-240320DB-CTXP: Technical Specifications
| Size | 2.4" Diagonal |
|---|---|
| Resolution | 240x320 Pixels |
| Colors | 262K |
| Display Type | IPS |
| Display Mode | Transmissive |
| Optimal View | Full View |
| Touchscreen | None |
| Outline L x W x H | 42.72mm x 59.46mm x 2.2mm |
| Viewing Area L x W | 39.30mm x 51.40mm |
| Active Area L x W | 36.72mm x 48.96mm |
| Supply Voltage | 3.0V |
| Luminance | 450 Nits |
| Interface | 8/9/16/18-bit Parallel, 6/16/18-bit RGB, or 3/4-wire SPI |
| Compatibility | Arduino or similar development boards |
| Controller Type | ILI9341V |
| Connection Type | 45-Pin FFC |
| Operating Temperature | -20° C ~ 70° C |
| Storage Temperature | -30° C ~ 80° C |
| Built-In Mounting | None |
| Built-In EMI Shielding | Yes |
