Dependable 20x2 STN (+) Yellow-Green Character LCD with Yellow-Green Backlight
Choose the NHD-0220DZ-FL-YBW for a strong display experience in your next build. It features a STN (+) Yellow-Green screen with a Yellow-Green backlight and transflective display technology, delivering reliable readability across lighting environments. A 6:00 optimal view angle ensures visibility from many perspectives. With the capable ST7066U controller and Parallel interface, integration with Arduino and similar development boards is seamless-so you can stay focused on refining your design.
This display runs on a standard 5.0V supply, operates between -20° and 70° Celsius, and is RoHS compliant, making it environmentally friendly, even if the environment might not be friendly to it.
NHD-0220DZ-FL-YBW: Technical Specifications
| Size | 2 Row | 20 Characters |
|---|---|
| Display Format | 20x2 |
| Total Characters | 40 |
| Display Type | STN (+) Yellow-Green |
| Display Mode | Transflective |
| Optimal View | 06:00 |
| Outline L x W x H | 116mm x 37mm x 13.9mm |
| Viewing Area L x W | 83mm x 18.6mm |
| Active Area L x W | 73.5mm x 11.5mm |
| Supply Voltage | 5V |
| Backlight | Yellow-Green |
| Interface | Parallel |
| Compatibility | Arduino and Similar Development Boards |
| Controller Type | ST7066U |
| Connection Type | 2x8 Thru Hole with 2.54mm Pitch |
| Operating Temperature | -20° ~ 70° C |
| Storage Temperature | -30° ~ 80° C |
| Additions | Mounting Holes |
6 Reviews
-
A+ quality and shipping
Good quality, fast shipping, and customer service is great. Competitive prices but we aware they may not have some products in stock.
-
Ok
Good quality display. Ok pricing.
-
品質
We haven been using this display on a product development project that involves a lot of vibration and this is by far the best performing display of all we have tested. Customer service is great and their engineering team is always helpful and responsive.
-
Easy setup and good quality.
I was able to use this display for one of my projects using 4-bit communication. Support was great and responsive. Product quality is excellent.
-
Fast US shipping
Fast US shipping and good quality product.
-
良い
I have been using this display for many years and has served my purposes very well. Backlight is bright and the documentation is very easy to follow.
