LCD simple de 8x1 STN (+) con caracteres amarillo-verde y sin retroiluminación
Perfect for bright environments, the NHD-0108BZ-RN-YBW-33V offers a STN (+) Yellow-Green display with no backlight and a reflective screen for clear readability in direct light. Its 6:00 optimal viewing angle ensures visibility from a variety of positions. The integrated ST7066U controller supports the Parallel interface, making integration with Arduino and similar development boards quick and painless, so you can focus on the rest of your project.
This display runs on a low 3.3V supply, operates between -20° and 70° Celsius, and is RoHS compliant, making it environmentally friendly, even if the environment might not be friendly to it.
NHD-0108BZ-RN-YBW-33V: Especificaciones técnicas
| Size | 1 Row | 8 Characters |
|---|---|
| Display Format | 8x1 |
| Total Characters | 8 |
| Display Type | STN (+) Yellow-Green |
| Display Mode | Reflective |
| Optimal View | 06:00 |
| Outline L x W x H | 53mm x 24.2mm x 11mm |
| Viewing Area L x W | 35mm x 12.6mm |
| Active Area L x W | 32.8mm x 11.6mm |
| Supply Voltage | 3.3V |
| Backlight | None |
| Interface | Parallel |
| Compatibility | Arduino and Similar Development Boards |
| Controller Type | ST7066U |
| Connection Type | 2x7 Pins with 2.54mm Pitch |
| Operating Temperature | -20° ~ 70° C |
| Storage Temperature | -30° ~ 80° C |
