Breakout Board for 1.5 inch Color OLED Glass

(No reviews yet) Write a Review
Model:
NHD-1.5-Breakout
Compatible With:
NHD-1.5-128128G
Interface:
Parallel / Serial
Resources:
$12.50
  • 1.5 inch Color OLED Glass Breakout Board front
  • 1.5 inch Color OLED Glass Breakout Board back

NHD-1.5-Breakout | Board is Compatible with NHD-1.5-128128G | On-board DC Circuit Booster | Open Source Hardware

Work smarter and faster with your color OLED glass using our OLED breakout boards. This breakout board was designed specially for our 1.5 inch OLED Glass display. This compact board come equipped with an on-board DC circuit booster to power on your OLED and start working right away. With this board you’ll be able to wire your display to any MCU and see your design in action, and because of their small size, you won’t be limited when it comes to finding the perfect placement in your application. This development tool features open source hardware, a power LED indicator, parallel or serial interface, 3.5mm mounting holes, and an operating temperature range from -40 to 70 degrees Celsius.

Product Specifications

Function: OLED Glass Breakout Board
Compatible With: NHD-1.5-128128G
Connection Type: 2x13 Thru-hole 2.54mm Pitch
Outline L x W x H: 60mm x 60mm x 3.6mm
Interface: Parallel / Serial
Hardware: Open-Source
Operating Temperature: -40°C ~ 70°C
Storage Temperature: -40°C ~ 85°C
Built-in Mounting: 3.5mm Mounting Holes
Added Feature: Power LED Indicator
