NHD-0216SZ-NSW-BBW-33V3 | 16x2 Character Display | Transmissive LCD | Side White Backlight | STN (-) Negative Blue Display 3.3V
Newhaven 16x2 character Liquid Crystal Display shows characters with white pixels on a blue background when powered on. This transmissive LCD Display requires a backlight for visibility while offering a wide operating temperature range from -20 to 70 degrees Celsius. This NHD-0216SZ-NSW-BBW-33V3 display has an optimal view of 6:00. This display operates at 3.3V supply voltage and is RoHS compliant.
LCD Product Specifications
|Number of Characters:||32|
|Display Type:||STN (-) Blue|
|Outline L x W x H:||122.0mm x 44.0mm x 13.5mm|
|Viewing Area L x W:||99.0mm x 24.0mm|
|Active Area L x W:||95.2mm x 20.0mm|
|Connection Type:||1x16 Thru Hole with 2.54mm pitch|
|Operating Temperature:||-20°C ~ 70°C|
|Storage Temperature:||-30°C ~ 80°C|
