5" Sunlight-Readable HDMI IPS TFT display for seamless embedded integration
This 5.0-inch IPS TFT LCD delivers vivid 800x480 resolution and exceptional clarity, even in bright outdoor environments, thanks to its ultra-bright 1,100-nit backlight. Built on a custom USA-engineered PCB with integrated HDMI compatibility and EMI shielding, this display is ready for demanding embedded applications that require reliable, high-quality visuals without touch functionality.
Designed for quick, cable-efficient setup, this module uses a Texas Instruments TFP401A HDMI/DVI receiver and built-in PWM LED driver for consistent performance. Ideal for use with Raspberry Pi, BeagleBone, and most HDMI-compatible systems, including Linux and Windows Embedded. While most Linux-based systems support plug-and-play functionality, Raspberry Pi users may need to adjust the config.txt file for full compatibility. Mounting is simple with the pre-installed steel brackets and no external enclosure required. As with all our displays, this module is RoHS compliant and built to meet strict environmental and safety standards.
NHD-5.0-HDMI-N-RSXP: Technical Specifications
| Size | 5" Diagonal |
|---|---|
| Resolution | 800x480 Pixels |
| Color | 24-Bit True Color |
| Display Type | Sunlight Readable IPS |
| Display Mode | Transmissive |
| Optimal View | Full View |
| Touchscreen | None |
| Outline L x W x H | 135.8mm x 75.8mm x 15.8mm |
| Viewing Area L x W | 109mm x 65.8mm |
| Active Area L x W | 108mm x 64.8mm |
| Supply Voltage | 5.0V |
| Luminance | 1,100 Nits |
| Interface | HDMI |
| Compatibility | Raspberry Pi, BeagleBone, and similar boards |
| Controller Type | TFP401A |
| Connection Type | HDMI |
| Operating Temperature | -20° C ~ 70° C |
| Storage Temperature | -30° C ~ 80° C |
| Built-In Mounting | 3.5mm Mounting Holes |
| Built-In EMI Shielding | Yes |
