Convenient 20 Circuit Easy-On Molex FFC/FPC Connector
Built for robustness and ease of use, the Molex_52271-2079 is an excellent choice for connecting 20 circuit FFC or FPC cables to a board. It features straightforward surface mounting, with right-angle orientation to give you flexibility in routing cables through your design or prototype. It features tin silver bismuth-plated phosphor bronze contacts with a 1mm pitch for a reliable connection and operates in temperatures ranging from -40 to 85°C, allowing it to perform its best even in extreme environments.
Molex_52271-2079: Technical Specifications
| Circuits | 20 |
|---|---|
| Pitch | 1mm |
| Positions | Bottom Contact |
| Actuator Type | ZIF |
| Net Weight | 277.003/mg |
| Mounting Angle | Right Angle Board Mount |
| Mounting Style | SMD/SMT |
| Contact Material | Phosphor Bronze |
| Contact Plating | Tin Silver Bismuth |
| Housing Color | Natural |
| Operating Temperature | -40° ~ 85°C |
| Flammability Rating | UL94V-0 |
| Current Rating | 0.5A |
| Voltage Rating | 50V AC/DC |
