Versatile Breakout Board 20 Pin FFC Connector and 2x10 Pin Header
The NHD-FFC20-1 is built to help you jumpstart your project with minimal setup. It features a 1mm pitch 20 pin FFC connector on one side and a 2x10 pin header on the other, offering a stable and reliable interface. Its compact size allows for versatile mounting options, making it ideal for both prototypes and finished designs.
NHD-FFC20-1: Technical Specifications
| Function | FFC Breakout Board |
|---|---|
| Connection Type | 20 Pin 1mm Pitch FFC Connector, 2.54mm Pitch 2x10 Pin Header |
| Outline L x W | 30mm x 18mm |
