NHD-2.7-12864WDW3 | 128x64 Pixels | Graphic OLED Module | White Monochrome Color | Serial or Parallel Interface
This 128x64 resolution graphic OLED display offers high contrast viewing with vibrant white graphics set against a deep black background. The OLED display technology is self-illuminating and engineered to provide high visibility and ensure easy readability from any angle in different environments. With this OLED, you can expect top speed response times. It is a passive-matrix display built with 6800/8080 serial or parallel interface options, and it’s fully compatible with Arduino, which allows for seamless integration with many different electronic systems for a wide range of applications.
Designed to withstand extreme operating conditions, the NHD-2.7-12864WDW3 model operates exceptionally when used within a temperature range from -40 to 85 degrees Celsius. It has a built-in SSD1322 controller, requires a 3.3V power supply for operation, and is RoHS compliant.
OLED Product Specifications
| Size: | 2.7" diagonal |
| Display Format: | 128x64 Pixels |
| Display Type: | Graphic OLED Module |
| Display Color: | Monochrome White |
| Outline L x W x H: | 82.0mm x 47.5mm x 5.5mm |
| Viewing Area L x W: | 63.41mm x 32.69mm |
| Active Area L x W: | 61.41mm x 30.69mm |
| Supply Voltage: | 3.3V |
| Interface: | Serial / Parallel |
| Compatibility: | Arduino and similar development boards |
| Controller Type: | SSD1322 |
| Connection Type: | 1x20 Thru Hole with 2.54mm pitch |
| Operating Temperature: | -40°C ~ 85°C |
| Storage Temperature: | -40°C ~ 85°C |
