4/9/2018
Introducing Mountable TFT Displays
Newhaven Display is unveiling a new line of Mountable TFT Displays. These 32 new TFTs are paired with a tough steel bracket and can be found in many different sizes. The steel bracket makes mounting these displays both convenient and extra-secure. You'll find Mountable TFT Displays in ...3.5”, 4.3”, 5.0”, 7.0”, and even 10.1” sizes.
+ see more
1/8/2018
New 5" & 7" HDMI TFT Modules
www.hdmitfts.newhavendisplay.com
The product line is made up of three 5-inch TFT modules and nine 7-inch TFT modules. The 5” versions all come with MVA technology (meaning exceptional 75° viewing at all angles) and your choice of capacitive, resistive, or no touch panel. The 7” modules have the same selection of touch screen options, but also allow you to choose between ...Standard, Premium, or Sunlight Readable TFT displays.
+ see more
Details
These new HDMI TFT Modules greatly simplify the process of connecting to the display. Rather than juggling an FPC ribbon cable with a middle-man controller board, you can connect an HDMI cable from your desired board or computer right into the TFT module. This makes it easy to interface with your display from the development and prototyping stages, all the way into final application production.
The incredible ease-of-use of these new products follows through into their touch panel integration as well. For both the resistive and capacitive (PCAP) touch panel options, USB-HID driver recognition is installed. Each of the touch panel modules are also each pre-calibrated in-house to the display they're mounted on. This means that a simple USB to micro-USB cable just needs to be connected from your board with touch interaction output (i.e. Raspberry Pi) to the module and your touch interactivity is ready to go immediately.
The boards that make up the new product line are of our own design and come with a number of features. On board DC power allows the display to perform at maximum capacity without worrying about a power supply bottleneck from elsewhere. The no-touch panel versions have just two simple connections required to get the module up and running, DC power and HDMI interface. The touch versions need an additional cable to utilize their touch functionality via USB-HID – three cables and you're ready to go. The hardware is compatible with PC systems (Windows or Linux) as well as Single-Board-Computers (SBCs) like the RaspberryPi and BeagleBone.
The HDMI TFTs' PCB boards also have four 3.5mm mounting holes tooled right into the board itself – no bracket or casing required, just pop in any standard M3 screws. To ensure the highest quality and long-lasting performance, these modules use the reliable Texas Instruments TFP401A HDMI/DVI receiver and the TPS61165 LED driver.
On the boards, you'll also find a switch for Pulse Width Modulation (PWM) to control the brightness output from the display backlight. All hardware is completely open source and available as a useful reference point for any interested user.
The wait for HDMI compatibility is over. Today is the day to start designing your projects with Newhaven Display's new HDMI TFT Modules. Stop limiting yourself to the hassles of FPC cables and clunky controllers, just grab an HDMI cable and your set up is complete. It's Newhaven Display's product quality fused with the reliability of HDMI interface.
Features
- – Standard High Definition Multimedia Interface (HDMI)
- – USB-HID Capacitive Touch Panel / USB-HID Resistive Touch Panel
- – Standard, Premium, and Sunlight Readable Variants
- – Instant Set-up
- – Compatible with PC (Windows / Linux) and SBCs such as RaspberryPi & BeagleBone
- – On-board Texas Instruments TFP401A HDMI/DVI Receiver
- – On-board Texas Instruments TPS61165 High Brightness LED Driver with PWM
- – 800x480 pixel resolution
- – 4x 3.5mm Mounting Holes for Standard M3 / #6-32 Screws Integrated with the Board
- – Open Source Hardware
- – Engineered and Assembled in Elgin, IL USA
- – RoHS compliant
Purchase Products
NHD-5.0-HDMI-N-RTXL
NHD-5.0-HDMI-N-RTXL-CTU
NHD-5.0-HDMI-N-RTXL-RTU
NHD-7.0-HDMI-N-RTXL
NHD-7.0-HDMI-N-RTXL-CTU
NHD-7.0-HDMI-N-RTXL-RTU
NHD-7.0-HDMI-N-RSXV
NHD-7.0-HDMI-N-RSXV-CTU
NHD-7.0-HDMI-N-RSXV-RTU
NHD-7.0-HDMI-N-RSXN
NHD-7.0-HDMI-N-RSXN-CTU
NHD-7.0-HDMI-N-RSXN-RTU
- see less
12/11/2017
New EVE2 TFT Modules in 3.5", 4.3", 5.0", and 7.0" Sizes
www.eve2tftmodules.newhavendisplay.com
The extremely powerful EVE2 generation of integrated circuits (ICs) are now available with new TFT display modules from Newhaven Display International. Newhaven Display has teamed up with FTDI/Bridgetek to create a high quality full color display product backed by the ...feature-rich FTDI EVE2 Graphic Engine.
+ see more
Details
The product line is made up of twenty different modules ranging in size from 3.5" diagonal to 7.0" diagonal. They also come with options for resistive or capacitive touch panels, as well as Newhaven Display's Standard, Premium, and Sunlight-Readable display variants. For the first time ever, these new products allow you to connect to a Newhaven Display TFT via SPI interface. The modules are packaged with fully integrated capability for video, audio, and touch interactivity.
With Newhaven Display's EVE2 TFT Modules, you will find two standard 20-pin connection options on every board – a 1.0mm FFC and a 2x10 2.54mm IDC connection. Both of these connector options will bring you the full power of the integrated EVE2 IC, without ever sacrificing display brightness. Typical TFT Modules will compromise the backlight brightness to accommodate the featured IC; however with Newhaven Display's EVE2 Modules, the full potential of the display's backlight luminance is available and can be adjusted as needed with the Pulse-Width Modulation controls available on each model.
Like never before, communication with these Newhaven Display EVE2 TFT Modules is done via serial (SPI or QSPI) interface. This offers you the ability to keep your microcontroller costs low while still providing a rich list of features thanks to the FTDI/Bridgetek Graphic Engine. SPI interfacing expends less pins (I/O) and the IC source is the latest and greatest, so you can design these products into your project without fear of near obsolescence.
The EVE2 TFT Modules are powered by FTDI/Bridgetek's FT812 & FT813 Embedded Video Engines. These powerful chips bring the EVE2 TFT Modules many different capabilities. You'll be able to utilize high resolution graphics, touch interactivity, video playback (with QSPI from your controller), and audio synthesization & playback if a speaker is installed with your application. The EVE2 supports multiple image formats (JPG, PNG, AVI, among others) as well as widgets to streamline touch interactive features of the display. There is 1MB of built-in graphics memory (RAM) and no external frame buffer is required. For touch development, the EVE2 supports up to 255 "touch tags" for quickly and easily recognizing and tracking touch movement. It also facilitates rapid prototype development with built-in scalable fonts and support for both portrait and landscape orientations. You can also take advantage of example code and resources from the Newhaven Display GitHub library, as well as FTDI/Bridgetek's excellent community and collection of open source resources/tools for the EVE2.
This new EVE2 TFT Module product line is composed of 3.5", 4.3", 5.0", and 7.0" sizes (measured diagonally). The 5.0" version comes as a Premium MVA module with the option for either resistive or capacitive touch. The 3.5", 4.3", and 7.0" sizes are available in Newhaven Display's Standard, Premium, or Sunlight Readable variants and also each have the option for either resistive or capacitive touch panel support. This makes for twenty total products to choose from.
With such a wide range of options, a rich list of features, and so many capabilities never before seen from Newhaven Display products, there's an EVE2 TFT Module that can bring new life to any display project. Each and every product has a crisp, high-quality Newhaven Display TFT and the super powerful, feature-rich EVE2 from FTDI/Bridgetek. With this combination, there's nothing these displays can't accomplish.
Features
- – TFT Display Modules Fully Integrated with Touch and Audio Control
- – SPI Interface for Communication
- – Two Industry-Standard 20-pin Connection Options on Every Board; FFC & IDC
- – 1MB of Built-in Graphics Memory (RAM) (no external frame buffer required)
- – On-board LED Backlight Driver that Will Never Compromise Brightness
- – Pulse Width Modulation Backlight Control
- – Supports Multiple Image Formats, Widgets, Video and Audio Playback
- – Includes Audio Synthesization Capability
- – Built-in Scalable Fonts
- – Support for Up to 255 Touch Tags for Tracking Touch Movement
- – 4 Mounting Holes for Standard M3 Screws Integrated with the Board
- – Portrait and Landscape Orientations Supported
- – Open Source
- – Engineered and Assembled in Elgin, IL USA
- – RoHS compliant
Purchase Products
NHD-3.5-320240FT-CTXL-T
NHD-3.5-320240FT-CSXV-T
NHD-3.5-320240FT-CSXN-T
NHD-3.5-320240FT-CTXL-CTP
NHD-3.5-320240FT-CSXV-CTP
NHD-3.5-320240FT-CSXN-CTP
NHD-4.3-480272FT-CTXL-T
NHD-4.3-480272FT-CSXV-T
NHD-4.3-480272FT-CSXN-T
NHD-4.3-480272FT-CTXL-CTP
NHD-4.3-480272FT-CSXV-CTP
NHD-4.3-480272FT-CSXN-CTP
NHD-5.0-800480FT-CTXL-T
NHD-5.0-800480FT-CTXL-CTP
NHD-7.0-800480FT-CTXL-T
NHD-7.0-800480FT-CSXV-T
NHD-7.0-800480FT-CSXN-T
NHD-7.0-800480FT-CTXL-CTP
NHD-7.0-800480FT-CSXV-CTP
NHD-7.0-800480FT-CSXN-CTP
- see less
3/27/2017
New 7" BeagleBone Capes
www.7beaglebonecapes.newhavendisplay.com
The Newhaven Display 7" BeagleBone Cape product line features three Capes. Each one is mounted to either a Standard, Premium, or Sunlight-Readable 7-inch Newhaven Display TFT and are designed for use with a BeagleBone Black board (created & sold separately by beagleboard.org). Engineered and assembled in Elgin, IL USA, these new Capes make display prototype developing easy for both current and aspiring BeagleBone users. The simple "plug and play" structure allows you to get right to development – even with Android or ...Linux operating systems.
+ see more
Details
The 7" BeagleBone Capes' use of BeagleBone development technology means the user can utilize the BeagleBone community and open source resources to facilitate the design process. In addition to the BeagleBone community resources, Newhaven Display provides Operating System images (OS images) written specifically for use with the 7" Cape's featured TFT display. The Capes also have a secondary Cape slot present to supplement your BeagleBone development with any other Capes you may need. The amazing BeagleBone community, along with these specially designed Capes, creates a realm of endless possibilities.
The new 7" BeagleBone Capes are paired with various Newhaven Display TFT options. The featured display options are an NHD-7.0-800480EF-ATXL#-CTP, an NHD-7.0-800480EF-ASXV#-CTP, or an NHD-7.0-800480EF-ASXN#-CTP. These part numbers represent Newhaven Display's Standard, Premium and Sunlight-Readable 7" TFT technology. All of the displays that come with these 7" BeagleBone Capes feature an 800x480 pixel resolution, 24-bit true color, as well as an integrated full-featured capacitive touch panel.
The sizable 7-inch display area on the TFT provides ample real-estate for touch interactivity. The capacitive touch panel that comes standard on the 7" BeagleBone Capes supports 5-point simultaneous touch input and gestural functionality. By integrating touch technology with the BeagleBone Black board, the user can take full advantage of the built-in touch capabilities of operating systems such as Linux or (especially) Android. This means you can begin touch-interfacing with the display in just a few steps by utilizing our available OS images designed specifically for these Capes. The TFT display and touch panel bring a lot of functionality to the 7" BeagleBone Capes, but the real power lies in the brilliant design of the Capes themselves.
The on-board hardware of the 7" BeagleBone Capes was designed to optimize usability with the BeagleBone Black. There are secondary headers to attach additional Capes if desired, enabling the expansion of the product development. Mounting the display is made easy by the four 3.5mm mounting holes compatible with standard M3 screws. A reset button is added allowing for easy access to BeagleBone Black's reset function covered up by the Cape. There's also on-board dip switch for configuring EEPROM – customize the memory however you see fit. A power LED indicator and write protection pins are integrated as well as PWM backlight control. These features make the 7" Capes an ideal companion to the BeagleBone Black.
Leave behind complicated development setups for a compact and powerful 7" BeagleBone Cape. It's a high quality 7-inch Newhaven Display TFT together with a full-featured custom BeagleBone Cape in one neat package. Simply plug the Cape into your BeagleBone Black and open up the world of possibilities that awaits.
Features
- – Three 7" BeagleBoneBlack Capes: Standard, Premium, and Sunlight-Readable display options
- – Android & Linux operating system support
- – Secondary BeagleBone cape slot
- – Open Source Hardware and Software
- – Four 3.5mm mounting holes
- – 5-point multi-touch capacitive touch panel
- – 800x480 pixel resolution
- – 24-bit true color
- – PWM backlight control
- – RoHS compliant
Purchase Products
NHD-7.0CTP-CAPE-L
NHD-7.0CTP-CAPE-V
NHD-7.0CTP-CAPE-N
- see less
10/17/2016
New 4.3" Arduino Shields
www.43arduinoshields.newhavendisplay.com
Effortless touch development is obtained with Newhaven Display's new Arduino Shields customized for their 4.3" capacitive or resistive touch TFT display line. Available in six display variations, these shields are ready to mate with some of Arduino's most commonly used development boards. Newhaven Display's 4.3" Arduino Shields are designed to ... be a simple compact solution for developing with touchscreen capable TFT displays.
+ see more
Details
The 4.3" Arduino Shields are available in six different models. Each shield features a 480x272 resolution TFT in the form of a Sunlight Readable, Premium (MVA) or Standard LCD display type. In addition to these three different display types, there are two different touchscreen options to choose from: 5-point multi-touch capacitive or 4-wire resistive touch. These shields feature the FT801 (capacitive touch) or the FT800 (resistive touch) video engine by FTDI which may be used to develop and demonstrate the functionality of the FT80X IC's and Newhaven's 4.3" touchscreen TFT displays. A bonus of these shields is the PWM (Pulse Width Modulation) which is the type of digital signal used to control the dimming of backlight LEDs. Since the Arduino Development boards are powerful tools, a micro SD slot also comes as a built-in standard allowing additional storage space for more complex code. This eliminates any memory constraints of the Arduino board. Additionally, the shields generate audio output with an on board power amplifier.
Engineered in Elgin Illinois, these 4.3" Arduino Shields were designed by Newhaven engineers for classic Arduino boards such as UNO, Mega and Leonardo. Each Arduino board connects directly to the back of the shield, greatly reducing software and hardware development time and simplifying the design process. No extra controller boards or messy cables are required, providing a much faster and effortless experience developing with a touchscreen TFT. By utilizing Arduino's vastly growing community, engineers can take advantage of shared code developed by other engineers as well as code created by Newhaven's engineers. To help engineers get started with the 4.3" Arduino Shields, Newhaven Display shares a repository of example code to get any engineer up and running as soon as the product arrives. Additionally, the open source hardware and software design will save engineers time and money. With all of these unique features and more, the 4.3" Arduino Shields are the best and quickest method for developing with touch TFTs.
Features
- – Connects with Arduino Uno, Mega and Leonardo
- – Standard, Premium (MVA) and Sunlight Readable TFTs
- – FT801 and FT800 video engines
- – PWM backlight control
- – Open Source Hardware and Software
- – Micro SD slot for expandable memory
- – 5V tolerant buffers
- – Generates mono audio output
- – RoHS compliant
Purchase Products
NHD-4.3CTP-SHIELD-N
NHD-4.3CTP-SHIELD-V
NHD-4.3CTP-SHIELD-L
NHD-4.3RTP-SHIELD-N
NHD-4.3RTP-SHIELD-V
NHD-4.3RTP-SHIELD-L
- see less
10/10/2016
New 2x16 Modular OLEDs
www.modularoleds.newhavendisplay.com
Organic Light Emitting Diode (OLED) displays are an easy fit for any application with Newhaven Display's new 2x16 Modular OLED product line. Choose between three electrical interfaces and five connector options for these character OLED displays. The modulated characteristics were designed with ...all kinds of engineers' project requirements in mind. With these new adaptable, small-scale modules it's easy to incorporate all the benefits of OLED technology and more into your existing or upcoming projects.
+ see more
Details
The 2x16 Modular OLED product line was designed and engineered in Elgin, IL U.S.A. These new modules are two-row by sixteen-character OLED displays. These displays output blue colored characters at a 10,000:1 contrast ratio, using three built-in font tables, and their biggest advantage is the components and infrastructure that make up the different modules.
Each of the six new Modular OLED displays come with a unique combination of electrical interface and connection options. The available interfaces to choose from are Parallel, SPI, and I²C. Five distinct connection options are available: two dual row pin headers in 2x18 (for Parallel interface only) or 2x8 sizes, two single row through-hole pin outs (in either 1x7 or 1x8 sizes), and an RJ45 port.
Features
- – Six new 2x16 Character OLED modules, each with unique connection and interface combinations
- – Parallel, I²C, or SPI interface options
- – 2x18/2x8 pin header, 1x7/1x8 through-hole, or RJ45 connectors
- – Industrial operating temperature range (-40°C – +85°C)
- – 10,000:1 contrast ratio and 10μsec response time
- – 2.8V or 5.0V selectable logic power levels
- – Built-in screen saver, and ultra low-power (<1mA) sleep mode
- – Any angle readability
- – RoHS compliant
Purchase Products
NHD-0216MW-PB3
NHD-0216MW-SB3
NHD-0216MW-EB3
NHD-0216MW-IB3
NHD-0216AW-SB3
NHD-0216AW-IB3
- see less
1/25/2016
New Color OLED Arduino Shields
www.colorarduino.newhavendisplay.com
Eliminate long color OLED development time with our new Color OLED Arduino Shields. Available in three sizes, these shields come ready to mate with some of Arduino's most commonly used development boards. In addition to these Color OLED Arduino Shields, ...standard off-the-shelf color OLED modules are available making it easy to develop with more than one size. Newhaven Display's Color OLED Arduino Shields are designed with all levels of engineers in mind looking to upgrade their current project with a more advanced, low power display technology.
+ see more
Details
Engineered in Elgin, IL USA, the Color OLED Arduino Shields offer any level of engineers an affordable and efficient way to begin development with Newhaven Display's Color OLEDs. These shields aid in bridging the gap between all types of users since they are easy to use, quick to market, affordable, and are a part of a great engineering community. The Color OLED Arduino Shields are not only restricted to engineers, they are the perfect tool for teaching various aspects of display development and can easily be adapted to a classroom setting. Designed by engineers for engineers, these shields come ready to take any idea into product realization.
Features
- – Designed to mate with Arduino UNO and Arduino UNO SMD
- – Breadboard friendly
- – Open Source Hardware and Software
- – Three sizes available, 1.27", 1.5" and 1.69"
- – 3.3V - 5.0V ready
- – Micro SD slot
- – Built-in level shifting
- – Easy to use, clearly labeled pins
- – RoHS compliant
Purchase Products
NHD-1.27-AU-SHIELD
NHD-1.5-AU-SHIELD
NHD-1.69-AU-SHIELD
- see less
1/8/2016
New Character OLED Glass
For the first time, Newhaven Display now offers an OLED Glass option for purchase. Available in a 2x16 character format similar to the NHD-C0216CZ and NHD-C12832A1Z COG families, this new OLED Glass display stands out with its vivid blue color and high contrast .... Upgrade virtually any character application today with this thinner display design featuring enhanced optical characteristics.
+ see more
Features
- – 2 lines x 16 characters
- – Blue color
- – 1.6mm thickness
- – High contrast: 10,000:1
- – 3V or 5V supply
- – 24-pin FFC connector
- – Parallel, SPI or I2C MPU interface
- – 4 built-in font tables
- – Built-in US2066 controller
Purchase Product
NHD-0216MW-AB3
- see less
12/15/2014
New Slim Character OLEDs
Newhaven Display International, Inc. announces today the first line of slim character OLEDs. These new OLEDs bring to Newhaven Display's vast product line a more affordable OLED option that is half the thickness and twice the contrast. Available in 2x16, 2x20 and 4x20 character formats, the new slim OLEDs add additional color options to the OLED display line. Red, green, blue, and ...yellow color options are offered in each display size. These displays come packaged as a complete module that includes all required logic at only a 5mm thickness. With 3 built-in font tables, 10,000:1 contrast ratio, 10μsec response time, and built-in screen savers, these new displays will offer any industry an upgrade to their current monochromatic character application.
+ see more
8/4/2014
New Full Color OLED Displays
Newhaven Display International Inc.'s full color OLEDs are available in sizes 1.27", 1.5", and 1.69". Featuring 262K colors, these passive matrix displays have a sharper and crisper viewing quality when compared to LCDs because of their rich black levels and 2000:1 contrast ratio. These displays also have ...faster and smoother graphic animations because of their 10μsec response time. Full color OLED displays are perfect for any industry, especially consumer and handheld because of their low power consumption. These unique displays also include a module containing all necessary logic. They do not have a backlight, which enables them to be 5mm thin fully assembled. Available upon request, Newhaven Display's full color OLEDs can include a resistive or capacitive touch panel.
+ see more
Features
- – 18bit/262K colors
- – 128x96, 128x128, & 160x128 resolution sizes
- – >160° viewing angle
- – -30°C ~ +70°C operating temp
- – 2000:1 contrast ratio
- – Built-in controller
- – Serial/Parallel MPU interface
- – 256-step brightness
- – Low power
- – Built-in sleep mode
- – 10μsec response time
- – RoHS compliant
Purchase Products
NHD-1.27-12896UGC3
NHD-1.5-128128UGC3
NHD-1.69-160128UGC3
- see less
4/7/2014
New 7.0" TFT Displays with Capacitive Touch
Newhaven Display now offers capacitive touch to the 7.0" TFT display line. This new capacitive touch is available on both the economical and MVA 7.0" TFTs. With the distinct features of a TFT, along with the additional benefits of integrating capacitive touch, these displays ...are ideal candidates for any industry that wants to enhance the user interface experience.
+ see more
Details
The touch panel not only looks sleek, it also has interactive abilities, and is exceptionally durable in environments that may be exposed to water, dust, and grease. The capacitive touch panel supports five simultaneous touches, including swipe and zoom gestures, and can be activated with a bare finger, a capacitive stylus, or a touchscreen-compatible glove. Newhaven Display's capacitive touch panel comes with a built-in I2C interface controller, allowing for quick time to market while keeping development costs low.
7.0" Standard Capacitive TFT Features
- – Cost effective
- – Capacitive touch panel with built-in controller
- – 800xRGBx400 resolution
- – 16.7M Colors
- – 12:00 optimal view
- – Fast response time
- – LED backlight
- – 24-bit digital RGB interface
- – RoHS compliant
7.0" Premium Capacitive TFT Features
- – Wide viewing angles (75° all angles)
- – Capacitive touch panel with built-in controller
- – 800xRGBx400 resolution
- – 16.7M Colors
- – Fast response time
- – Intense color reproduction and depth
- – 24-bit digital RGB interface
- – RoHS compliant
Purchase Products
NHD-7.0-800480EF-ATXL#-CTP
NHD-7.0-800480EF-ATXV#-CTP
- see less
3/24/2014
New 4.3" IPS TFT Displays
Newhaven Display International is proud to introduce two new 4.3" IPS (In-Plane Switching) TFT displays to their display line. The new 4.3" IPS TFT technology features extra-wide viewing angles with consistent color reproduction. This is achieved by the horizontal arrangement of the liquid crystals that allows the backlight to easily pass through the liquid crystals without ...twisting and refracting. These TFTs also have fast response times, wide operating temperatures, are RoHS compliant, and are offered with and without resistive touch panels. They are the perfect match for any visually demanding application that requires a broader viewing angle.
+ see more
Features
- – 80deg. viewing angle
- – 480x800 resolution
- – Portrait mode
- – 16.7M Colors
- – Optional resistive touch panel
- – Built-in HX8369 controller
- – 8-LED backlight
- – 16-bit 8080 mode parallel MPU interface
- – Consistent color reproduction
- – RoHS compliant
- see less
2/17/2014
New 5.0" Resistive TFT Display
Newhaven Display International now offers a resistive touch option for the Premium 5.0" TFT display line. The new 5.0" resistive TFT is the perfect solution for bringing touch interaction to your application. This affordable 5.0" touch solution allows ...the end user to interact with the display by touch or a stylus and is available as part of the 5.0" Premium TFT line. This Premium TFT line features a 3M enhancement film for increased backlight brightness, a super high quality polarizer for extended viewing angles, and enriched picture quality.
+ see more
Features
- – 4-wire Resistive Touch Panel.
- – Enhanced Optical Characteristics.
- – 800xRGBx400 Resolution.
- – 16.7M Colors.
- – 12:00 Optimal Viewing Angle.
- – RoHS compliant
Purchase Product
NHD-5.0-800480TF-ATXL#-T
- see less
10/16/2013
New 2.4" TFT Display
Newhaven Display International is pleased to introduce our new 2.4" TFT to our display line. This new TFT features a resistive touch panel without printed icons, allowing the ...display to have a larger viewing area and more versatility. It also has a 12:00 optimal viewing angle, a wide operating temperature, and an updated controller that features more capabilities. This display works exceptionally well with all applications, including portable and handheld devices.
+ see more
Features
- – 240x320 pixels
- – 4-wire resistive touch panel
- – Built-in ILI9341 controller
- – 12:00 viewing angle
- – 8-bit or 16-bit parallel interface
- – FFC ZIF I/O connection
- – Wide operating temperature
- – RoHS compliant
- see less
10/1/2013
New 7.0" TFT Displays
Newhaven Display International, Inc. is proud to introduce two new 7.0" TFTs to their display line: the 7.0" Economical TFT and the 7.0" MVA TFT. The 7.0" Economical TFT and the 7.0" MVA TFT have full RGB color, fast response times, high brightness & contrast, ...wide operating temperatures, are RoHS compliant, and are offered with and without resistive touch panels. Each TFT offers unique features that are perfect for any industry.
+ see more
Details
The 7.0" Standard TFT display has a 12:00 optimal viewing angle and is available at an affordable cost. This display has the same high quality as Newhaven's standard 7.0" TFTs, but fits easily into a tighter budget. It's a perfect match for visually demanding applications.
The Premium display has an extended viewing angle of 150° (75° each angle). This improved viewing angle is achieved by its rigid polarizer, which extends the viewing angles while also retaining the intended color saturation giving the display great color reproduction and depth. This display works great with applications requiring a broader viewing spectrum.
7.0" Standard TFT Features
- – 800xRGBx400 resolution
- – Cost effective
- – 16.7M colors
- – 12:00 optimal view
- – Fast response time
- – 24-bit digital RGB interface
- – LED Backlight
- – Built-in driver/no controller
- – RoHS compliant
7.0" Premium TFT Features
- – 800xRGBx400 resolution
- – Wide viewing angles (150°/75° all angles)
- – 16.7M colors
- – Fast response time
- – 24-bit digital RGB interface
- – Intense color reproduction and depth
- – Built-in driver/no controller
- – RoHS compliant
Purchase Products
NHD-7.0-800480EF-ATXL#
NHD-7.0-800480EF-ATXL#-T
NHD-7.0-800480EF-ATXV#
NHD-7.0-800480EF-ATXV#-T
- see less
7/29/2013
New Premium 5.0" TFT Displays
Newhaven Display International, Inc. now offers premium versions of their 5.0" TFT displays. The new premium TFTs come either with a capacitive touch panel or without, and feature ...increased backlight brightness, extended wide viewing angles, and enriched picture quality. These key enhancements are perfect for more visually demanding applications.
+ see more
Details
The backlight on the new premium 5.0" TFTs is significantly brighter than the standard model. A 3M enhancement film was added with additional backlight LEDs to achieve a 450cd/m2 rating. The overall viewing angle was extended by using a super high quality polarizer. This polarizer extends the viewing angle from all directions when compared to the standard TFT displays.
Features
- – 3M enhancement film for increased backlight brightness.
- – Improved direct sunlight readability.
- – Super high quality polarizer for extended viewing angles.
- – Supports a broader viewing spectrum.
- – Enriched picture quality.
- – RoHS compliant
Purchase Products
NHD-5.0-800480TF-ATXL#
NHD-5.0-800480TF-ATXL#-CTP
- see less
6/6/2013
Now Offering PIC32 Adapter Board
Newhaven Display and Digi-Key have developed a new PIC32 Display Adapter Board, the NHD-3.5-320240MF-PIC Eval Board (DKSB1014B-ND). This display adapter provides the designer with a 3.5" resistive ...touch LCD (NHD-3.5-320240MF-ATXL#-T-1) and hardware interface for select Microchip PIC32 evaluation/starter kits: DM320003-2-ND, supporting Microship Low-Cost Controllerless graphics: AC164144-ND.
+ see more
Features
- – Newhaven 3.5" QVGA with resistive touch, NHD-3.5-320240MF-ATXL#-T-1.
- – Efficient Diodes Inc. white LED step-up backlight driver, AP5724WG-7DICT-ND.
- – AVX flat flex ZIF connector, 478-5598-1-ND.
- – 3M bump-on's for perfect mating to the Microchip evaluation boards, SJ5749-0-ND.
- – RoHS compliant
What you'll need in addition to the PIC Eval Board
- – DM320003-2-ND PIC32 USB II Starter Kit
- – AC164144-ND LCC PICtail Plus Daughter Board
Interface info, schematic, software files, and more
More info on PIC 32 Adapter Board
- see less
11/26/2012
New Multi-Font Displays
Newhaven Display is now offering multi-font Displays that feature a built-in IC that includes over 50 languages and 37 standard font tables and will be added in series to select graphic display types. This Multi-Font IC contains ASCII, Unicode, and ISO8859 tables for flexibility and compatibility. The fonts featured are ...either fixed width or proportioanl width and can be read at a clock rate up to 30mHz. When using this new display line, the user's MPU can communicate directly with this Multi-Font IC to read the font data strings and then out put the desired character onto the display. Using just a 4 wire SPI interface, the selected font data is read in vertical structrued bytes fromt he Multi-Font IC and is sent out to the display's controller.
+ see more
Details
Our Graphic OLED Displays are the first display family to feature this new multi-font capability. Multi-Font Display has predefined font tables. This eliminates the need to create your own characters. Multi-Font Displays also have a built-in IC that has 50+ languages and 37 font tables. This eliminates the need to spend money on additional memory to hold multiple languages. Multi-Font Displays use standard font tables such as...
Font Tables
- – ISO8859
- – 5x7 ASCII
- – 7x8 ASCII
- – 8x16 BOLD ASCII
- – Width-Adjusted Arial ASCII
- – 8x16 Latin
- – 8x16 Greek
- – 8x16 Thai
- – Width-Adjusted Latin
- – Width-Adjusted Greek
- – Width-Adjusted Cyrillic
- – Width-Adjusted Arabic
- – GB2312
- – 5x10 LCM
- – KSC5605
- – JIS0208
Purchase Products
Multi-Font Product Line
- see less
4/2/2012
New Capacitive Touch TFT Displays
Newhaven Display is now offering projective mutual capacitive touch TFTs with a built-in touch panel I²C interface controller. This allows for quick time to market while keeping your development costs low. The capacitive touch TFTs will be available in 3.5", 4.3" and 5.0" size TFTs. The capacitive touch panel is ...the ideal tool for enhancing the user interface experience with any TFT application. These touch panels have multi-touch ability and are extremely durable in most environments including withstanding water contact, dust and grease. Capacitive touch panels will activate with either a bare finger or a capacitive stylus and have excellent dragging performance.
+ see more
Features
- – Built-in touch panel controller with I2C interface (400KHz)
- – Projective Mutual Capacitive Touch Panels
- – 6mA at 3.3V power supply
- – 5 simultaneous touches: touch, lift, and zoom gestures
- – 6H hardness, >1 million touches
- – Sizes available: 3.5", 4.3", and 5.0" TFTs
- – 82% light transmittance
- – 0.03mA sleep mode
- – RoHS Compliant
- see less
9/19/2011
Now Offering Custom Keypads
Newhaven Display is now offering their expertise in creating affordable, high quality custom keypads for any industry. Everyday more and more interactive products are being utilized everywhere from PDAs and Industrial Controls, to Automotive and Medical Equipment.... Now, with our ability to provide custom keypads and utilizing our in-house engineering professionals, we can provide the most appropriate mix of technologies to fulfill any design requirement.
+ see more
Examples of Capabilities
- – Plastic keypads and plastic keycaps
- – Laser etched keypads
- – 3D and contoured key tops
- – Epoxy keypads
- – In-mold graphics
- – Phosphorescent keypads
- – Membrane keypads
- – Vibrant colored keypads
- – and many more...
- – All keypads are RoHS Compliant
- see less
5/9/2011
New Character and Graphic OLED Displays
The new OLED (Organic Light Emitting Diode) is a brighter, higher contrast display that has faster response times, wider viewing angles and consumes less power than conventional VFD, LED or LCD Displays. OLED displays are self-illuminating and require no backlight for maximum visibility in all environments. This also allows OLEDs to be significantly thinner ...than standard VFD, LED or LCD displays. Newhaven Display offers Character and Graphic type OLED displays as complete, easy-to-use modules.
+ see more
Details
Newhaven Display's Character OLED modules come in standard sizes and be used as drop-in replacements for LCD or VFD modules. They use serial or parallel MPU interface, have LCD compatible instructions and 4 built-in font tables.
Newhaven Display's Graphic OLED modules are easy to use, all-in-one designs. Most Graphic OLED displays require multiple high-voltage power supplies and external logic components. Newhaven Display's custom designd module boards for each Graphic OLED allow the user to have just one interface supply. The Graphic OLED module board has all the required external logic components, making it fast and easy to start using the displays.
Features
- – Fast response time: 10μs
- – Wide viewing angle: Up to 160°
- – Thin designs
- – Self-illuminated; no backlight necessary
- – Low power consumption
- – High Brightness
- – High Contrast ratio: 2000:1
- – Wide Operation Temperature: -40°C to +80°C
- – Serial or Parallel MPU interface
- – Character Module OLEDs include 4 built-in Font Tables
- – Graphic Module OLEDs include required external logic and voltages
- – RoHS Compliant
- see less
8/30/2010
New NHDev Development Board
The NHDev Board is the ideal tool for prototyping and evaluating Newhaven Display's COG, TFT, Character and Graphic LCD Displays. This STM32F based device comes preprogrammed to demonstrate each display with preloaded images ...and text files from the included SD Card. These files can also be easily edited or replaced with user created images allowing you to see what your actual application will look like.
+ see more
Details
The NHDev Board's easy-to-use functionality allows for quick time to market while keeping your development costs low. The design of the board has selection features making it easy for the user to plug in any display and with a push of a button have it up and running in moments versus days. The NHDev Board now gives you the freedom to pick and choose several displays instead of just one when prototyping your product.
Features
- – One board to evaluate several displays
- – Sample codes and wiring diagrams provided
- – CPU:STM32F103RET6 ARM 32 bit Cortex-M3
- – 2.54mm (0.1") pitch LCD development output pins and thru-holes
- – PCB dimensions: 100 x 95mm
- – SD Card storage with preloaded images and text files
- – NHD-C0216CZ-FSW-FBW display
- – 3 push button user interface
- – 7VDC power supply, jumper to select +5V, 3.3V LCD power supply
- – Jumper to select input to V0 potentiometer, either VSS or VEE (external voltage)
- – Variable resistor to adjust contrast
- – Backlight enable switch
- – MPU reset switch
- – JTAG connection with ARM2x10 pin layout for programming
For more information...
Contact nhtech@newhavendisplay.com
or
Click Here
- see less
10/9/2009
New Multi-Color I2C Interface Displays
Newhaven Display International, Inc. is offering a new lineup of Chip-On-Glass LCD Modules with I2C interface and built-in RED GREEN BLUE backlights. These new displays feature all the benefits of normal COG displays, and added to those is the design simplification of I2C ...interface and the hight-quality usability of multi-colored backlighting. The new R-G-B COG displays are ideal for all display applications to save processor I/O pins and to give the end user not only readable feedback in any lighting condition, but also bright and easy-to-read color notifications.
+ see more
New Features
- – I2C serial interfaces
- – Red-Green-Blue common cathode backlight
- – Save development time and I/O line
CoG Display Features
- – Low power LCD supply, ideal for handheld applications
- – With or without bright LED backlights
- – Small foot print, thin glass, no PCB
- – Simple hardware interface
- – Common LCD commands and software
- – Resistant to ESD with no metal bezel
- – Custom development available
- – RoHS Compliant
For more information...
Contact nhtech@newhavendisplay.com
- see less
9/15/2009
New LCD Serial Interface Displays
Newhaven Display International, Inc., is offering the industry's first lineup of Character LCD Modules with integrated RS232, I2C and SPI serial interfaces with a broad range of industry standard sizes in 2x16, 2x20 and 4x20 modules. With these new displays, there are no more bulky additional "daughter boards" which results in better usability and cost. Software controlled contrast and ...backlight brightness simplifies development and maximizes application performance. These new LCD Serial Displays are ideal for all display applications to save processor I/O pins. Quantity pricing and custom display solutions are also available.
+ see more
Features
- – I2C, SPI, and RS232 serial interfaces
- – Save development time and I/O lines
- – Simple hardware interfacing
- – Software controlled contrast and backlight brightness
- – Standard LCD commands and fonts
- – No extra boards or logic required, standard LCD sizes
- – Custom development available
- – RoHS Compliant
For more information...
Contact nhtech@newhavendisplay.com
- see less
|
